MIMIC LED Hand Lamp is useful inemergency situations, maintenance &production purpose.Highly reliable product designed andmanufactured in house for more strictquality control which is expected to workminimum 10 years.The strong and light weighted Aluminumextruded body, translucent glowing partmakes the MIMIC Hand Lamp a suitablefit for a variety of conditions.

MIMIC LED Hand Lamp is useful inemergency situations, maintenance &production purpose.Highly reliable product designed andmanufactured in house for more strictquality control which is expected to workminimum 10 years.The strong and light weighted Aluminumextruded body, translucent glowing partmakes the MIMIC Hand Lamp a suitablefit for a variety of conditions.

MIMIC LED Hand Lamp is useful inemergency situations, maintenance &production purpose.Highly reliable product designed andmanufactured in house for more strictquality control which is expected to workminimum 10 years.The strong and light weighted Aluminumextruded body, translucent glowing partmakes the MIMIC Hand Lamp a suitablefit for a variety of conditions.

MIMIC LED Hand Lamp is useful inemergency situations, maintenance &production purpose.Highly reliable product designed andmanufactured in house for more strictquality control which is expected to workminimum 10 years.The strong and light weighted Aluminumextruded body, translucent glowing partmakes the MIMIC Hand Lamp a suitablefit for a variety of conditions.

Product Type: Industrial LED Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 28 Watt
Operating Voltage: 24 VAC
Minimum Order Quantity: 1 Piece

Salient Features

• 10 years service life backed with 1 year warranty

• Operates on 24VAC supply for industrial applications

• 28 Watt high-power LED delivering approx. 2800 lumens

• Bright, uniform illumination for large working areas

• Robust aluminium extruded body for harsh environments

• Unbreakable polycarbonate dome with excellent light diffusion

• Ergonomic and insulated ABS handle

• Designed and tested as per IS 10322 (Part 5 / Section 6): 2013

• Suitable for emergency, inspection, maintenance, safety & production use

• Designed and manufactured in-house for long-term reliability

Technical Specifications

Luminous Output: 2800 Lumens
Light Source: High-power LED
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· Industrial plants

· Power panels

· Heavy equipment maintenance

Product Type: LED Inspection Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 14 Watt
Operating Voltage: 24 VAC
Minimum Order Quantity: 1 Piece

Salient Features

• Designed for 10 years expected life with 1 year warranty

• Operates on 24VAC industrial control voltage

• 14 Watt LED with uniform, glare-free illumination

• Strong yet lightweight aluminium extruded body

• Translucent unbreakable polycarbonate dome

• Shock-resistant ABS handle for safe handling

• Low heat generation for continuous inspection work

• Designed as per IS 10322 (Part 5 / Section 6): 2013

• Ideal for inspection, maintenance, safety & production environments

• Highly reliable product manufactured under strict quality control

Technical Specifications

Light Type: Diffused LED
Lumens: 1400
Brightness: Uniform inspection lighting
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· Electrical control panels

· Automation panels

· Industrial inspection tasks

Product Type: High-Brightness LED Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 28 Watt
Operating Voltage: 12 VDC
Minimum Order Quantity: 1 Piece

Salient Features

• Long operational life of minimum 10 years with 1 year warranty

• Operates on 12VDC low-voltage supply for enhanced safety

• High-brightness 28 Watt LED for powerful illumination

• Approx. high lumen output for detailed inspection

• Heavy-duty aluminium extruded housing

• Unbreakable polycarbonate glowing dome for impact resistance

• Ergonomic ABS handle for prolonged use

• Manufactured as per IS 10322 (Part 5 / Section 6): 2013

• Suitable for emergency, maintenance, production & safety lighting

• In-house manufacturing ensures consistent quality and reliability

Technical Specifications

Light Source: High-intensity LED
Lumens: 2800
Illumination: Bright, glare-free light
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· Heavy machinery inspection

· Mobile service units

· Industrial DC systems

· Maintenance workshops

Product Type: LED Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 14 Watt
Operating Voltage: 12 VDC
Minimum Order Quantity: 1 Piece

Salient Features

· Expected service life of up to 10 years with 1 year warranty

· Operates on safe low-voltage 12VDC supply

· Energy-efficient 14 Watt LED suitable for continuous use

· Strong aluminium extruded body for industrial durability

· Unbreakable translucent polycarbonate dome for uniform light diffusion

· ABS insulated handle ensures safe and comfortable grip

· Lightweight yet rugged construction for field applications

· Designed as per IS 10322 (Part 5 / Section 6): 2013

· Ideal for emergency lighting, inspection, maintenance & safety applications

· Designed and manufactured in-house for strict quality control

Technical Specifications

Light Source: High-brightness LED
Lumens: 1400
Luminous Output: High visibility inspection light
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· Automotive service stations

· Battery-operated systems

· DC control panels

· Industrial inspection & maintenance

Product Type: Heavy-Duty DC LED Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 28 Watt
Operating Voltage: 24 VDC
Minimum Order Quantity: 1 Piece

Salient Features

• Designed for long life up to 10 years

• Backed with 1 year warranty

• Operates on 24VDC supply for industrial DC systems

• 28 Watt high-brightness LED for intense illumination

• Approx. high lumen output for demanding applications

• Strong and corrosion-resistant aluminium extruded body

• Impact-resistant polycarbonate dome

• Ergonomic ABS handle for operator safety

• Complies with IS 10322 (Part 5 / Section 6): 2013

• Suitable for maintenance, inspection, emergency & production areas

• Highly reliable design manufactured under strict quality standards

Technical Specifications

Light Source: High-brightness LED
Lumens: 2800
Illumination: Intense & uniform
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· Heavy industrial maintenance

· Power & utility sectors

· Manufacturing facilities

MIMIC LED Hand Lamp is useful in emergency situations, maintenance & production purpose.Highly reliable product designed and manufactured in house for more strict quality control which is expected to work minimum 10 years.The strong and light weighted Aluminum extruded body, translucent glowing part makes the MIMIC Hand Lamp a suitablefit for a variety of conditions.

• LED Based.
• LED Expected life : 50,000 Hrs.
• Operating Voltage : 24 VAC.
• Unbreakable translucent borosilicate glass.
• Aluminum extruded Light weighted body.
• IP - 65 weather protection.
• 14 / 28 / 36 Wattage selectable in single model.
• Protective metal wire mesh.

Product Type: DC LED Hand Lamp
Brand: MIMIC
Model: Sparrow
Wattage: 14 Watt
Operating Voltage: 24 VDC
Minimum Order Quantity: 1 Piece

Salient Features

• Expected operational life of minimum 10 years

• Comes with 1 year manufacturer warranty

• Operates on 24VDC low-voltage DC supply

• 14 Watt LED for energy-efficient illumination

• Lightweight yet strong aluminium extruded housing

• Unbreakable polycarbonate light dome

• ABS insulated handle for safe DC operation

• Designed as per IS 10322 (Part 5 / Section 6): 2013

• Ideal for DC panels, emergency lighting & inspection tasks

• Manufactured in-house ensuring superior quality control

Technical Specifications

Light Output: Uniform LED illumination
Lumens: 1400
Ingress Protection: IP54
Operating Temperature: -40°C to +85°C

Applications

· DC panels

· Telecom & utility installations

· Battery-backed systems

LED HAND LAMP /Maintenance Hand Lamp/ SAFETY hand LAMP/Work Light/ Machin hand

1. Manufacturer and exporter of LED Hand lamp/Maintenance hand lamp/Safety hand lamp
2. Manufacturer in Ambernath,Thane, Maharashtra
3. Supplier to Defence, Railway and Cement Industry

Salient Features

• 800 Lumens
• 8 Watt
• Rechargeable
• Portable
• Wireless
• Inbuilt lithium Ion battery
• Transluscent Glow
• Polycarbonate dome
• 180 degrees viewing angle
• 3 hours back-up

Mechanical Charecteristics

1. Main Body :- Aluminium Extruded with heat dissipation fins
2. Glowing Part :- Polycarbonate Transluscent dome
3. Base Body :- ABS engineering Grade plastic
4. Handle :- ABS with heat resistant rubber coating
5. Hook :- Stainless Steel(SS)
6. Dimensions :- 240mm x 60mm Diameter
7. Weight :- 300 gram

Electrical Charectaristics

1. Power: 8 watt
2. Charging :- Through Charging socket
3. Control :- Through ON/OFF switch
4. Charging by :- Constant Current Constant Voltage(CCCV) charger
5. Charging Current :- 1 Amp
6. Hand Lamp Current :- 1 Amp

Optical details and Characteristics

1. Lumens :- 800
2. Type of LED :- 1Watt x 8
3. Illuminating type :- Diffused
4. Viewing Angle :- 180 degrees
5. Color Temperature :- 6500K
6. CRI :- Greater than 70
7. Glass :- Unbreakable PC

Other Chrecteristics

1. Weather Protection :- IP54
2. Warrantee :- 1 Year

Application

1. Maintenance Departments
2. Railways
3. Defense
4. Navy
5. Emergency services
